Technical Specifications
Features
Sizes
- Widths from 8’ to 18’, in 1” increments.
- Heights from 6’6” to 8’, in 3” increments.
Please contact us for more details on oversized doors available.
Colours
ALUMINUM (rustic woodgrain finish)
White
Universal Brown
Heron Blue
The accuracy of colours on the website may vary depending on your screen settings. To see the true colours, please contact your local Garaga dealer for a sample.
Layouts
Classic CC
Garaga construction makes all the difference
Rugged & Durable
Thermally Efficient
Refined Design
|
1
|
INTERLOKTM JOINT |
 |
Located between sections, this joint blocks air infiltration due to its triple-contact weatherseal. |
 |
Makes sections very strong as it is mechanically interlocked and not bonded. |
|
|
|
|
2
|
WOOD END BLOCKS |
|
The most effective thermal breaks, they eliminate any transfer of cold or heat between materials. |
|
|
|
|
3
|
REINFORCED METAL PLATES |
|
With 14-gauge thickness, they are used to solidly attach hinges, handles and operator bracket. |
|
|
|
|
4
|
HIGH-PERFORMANCE WEATHER STRIPPING |
|
Our weather stripping ensures increased weathertightness and stays flexible through the coldest temperatures. |
|
|
|
|
5
|
POLYURETHANE |
|
High-pressure injected foam provides R-16 thermal resistance for 1 ¾” doors. |
|
Because it adheres to the section walls, it provides a high level of rigidity to the door. |
|
|
|
|
6
|
CONTINUOUS WOODGRAIN |
 |
Up close or at a distance, our embossed woodgrain finish is flawless and very refined. |
|
|
|
|
7
|
MOLDED WINDOW FRAMES |
|
Both our interior and exterior window frames are molded without joints or any visible screws. They are made of synthetic resin that is sun resistant to keep their good looks over the years. |
|
|
|
|
8
|
FLEXIBLE TOP WEATHERSTRIPPING |
|
Installed on the interior side of the top section, it helps to make the door even more weathertight. |
